We Engineer Your Vision

Schematic Design

Analog / Digital schematics with best practices.

PCB Layout

1–6-layer boards with impedance control.

Fabrication

Turnkey PCB manufacturing & assembly.

Technical Highlights

Up to 6 layers

3–10 mil (down to 2 mil for HDI)

IPC-2221\IPC-7351 Compliance

Our Services

PCB Design & Layout

  • Reverse engineering
  • Schematic Capture & Netlist
  • Bom generation
  • Multi-layer Design (up to 6 layers)
  • High-speed signal routing (DDR, HDMI, USB, RF)
  • DFM/DFT checks
  • Design tools: Altium, OrCAD, EasyEDA
  • All designs follow IPC standards including: IPC-2221, IPC-7351, IPC-6012

PCB Manufacturing

  • Board Types: Rigid, Flex, Rigid-Flex
  • Material Options: FR4, FR4BLACK, MCPCB
  • Layer Count: 1–6 layers
  • Board Thickness: 0.3 mm – 3.2 mm
  • Copper Thickness: 1 oz – 3 oz
  • Min Trace/Space: 3 mil / 3 mil
  • Min Hole Size: 0.5 mm
  • Surface Finish: HASL, ENIG, Immersion Silver/Gold, lead free
  • Quality Standards: IPC Class 2 & 3, ISO 9001, RoHS compliant

PCB Assembly

  • Tech: SMT, THT, Mixed
  • Components: 0603 to LQFN, TQFN, SOIC, SOP
  • Testing: AOI, ICT, Functional Testing, Flying probe
